800kg Tilt Welding Turning Table for Flange Welding

Get precise and efficient flange welding with our 800kg Tilt Welding Turning Table. As a factory, we ensure top-quality equipment for your welding needs.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product standard/Optional
Overview

Basic Info.

Model NO.
BWJ-8
Max Eccentricity Distance
150mm
Tilting Angle
0-90°
Voltage
110V/220V
Condition
New
Function
Pipe Flange Welding Turning Table
Control Mode
Manual Box
Horizontal Loading Weight
800kg
Vertical Loading Weight
400kg
Rotation Speed
0.1-1rpm
Tilting Motor
Electrical
Rotate Motor
0.55kw
Turntable Diameter
1000mm
Tilt Angle
0-90 Degree
Tilt Speed
0.4rpm
Tilt Motor
0.55kw
Pedal Switch
Yes
Speed Control Mold
Frequency Conversion
Postioner Type
Seat Type
Power
AC380V 50Hz
Transport Package
Standard Package
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Production Capacity
30000PCS/Year

Packaging & Delivery

Package Size
135.00cm * 135.00cm * 80.00cm
Package Gross Weight
1000.000kg

Product Description

Product Description

800kg Tilt Welding Turning Table for flange welding

The welding positioner is mainly composed of four parts:
a flip working platform, a rotating working platform, a motor reducer, and a fuselage.
Among them, the rotating motor is installed under the rotating workbench.
The electrical part of the welding positioner is mainly composed of an electric control cabinet and a foot switch.
The positioner's forward rotation, reverse rotation, speed adjustment, start, and stop can all be realized in the electric control box or by using a foot switch. The operation of flange tilt turning welding positioner is simple and convenient.

Why choose Wuxi Lemar Machinery?
1.Quality assurance
Rigorous processing process, control of source materials, and technical support from many years of production experience
2.360 degree arbitrary rotation, angle flip 0-120 degrees
3. The flange pipe welding positioner operates stably
The welding time can be set, and the welding will automatically stop after the timer expires.
4. Welding positioner and welding rotary table are mostly used in ship pipe fitting manufacturing, steel structure engineering manufacturing, oil pipelines, special vehicles, pressure vessels and other places
4. Reasonable price
It saves the intermediate dealers and makes the price more competitive.

Wuxi Lemar Machinery Equipments Co.,Ltd is mainly engaged in welding column and boom operating machines, 0-360 degree rotation positioners (0-120 degree flip positioners), self-adjusting roller stands, adjustable roller stands, and portable CNC cutting machines , desktop CNC cutting machine, gantry CNC cutting machine. Welding and cutting equipment, with complete supporting varieties and reasonable prices, sell well all over the country and enjoy a high status among consumers.
Lemar company has established long-term and stable cooperative relationships with many retailers and agents.Lemar company has strong strength, values credit, abides by contracts, guarantees product quality, and has won the trust of customers with its multi-variety operating characteristics and the principle of small profits but quick turnover.
Lemar company's products are sold throughout the country and foreign markets. Sales business has been established with India, Indonesia, Malaysia, Russia, Australia, India, Japan, Germany, the United States, Canada, Poland, Zimbabwe, Brazil, France, Spain, Italy and other countries. Cutting-edge research and development capabilities, rigorous modern enterprise management model, and meticulous sales and after-sales tracking services have created Lemar's brand strength.
Product standard/Optional
Model BWJ-8
Loading weight 800kg positioner
Vertical loading weight 400kg
Rotate speed 0.1-1rpm
Rotate motor 0.55kw
Tilt mode Electrical
Tilt motor 0.55kw
Control mode Manual box
Turntable diameter 1000mm
Tilt angle 0-90 degree
Tilt speed 0.4rpm
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding

Wuxi Lemar's Product range of welding auxiliary equipment:
10kg/30kg/50kg/100kg/200kg/300kg CE certified light welding positioner;
Flange/pipe automatic welding machine;
Heavy-duty positioner with large through hole;
Pressure roller positioner/roller rotator;
Self-adjusting/adjustable welding roller rotator;
Carbon steel/stainless steel/aluminum alloy and other circular workpiece straight seam welding machine;
PLC control stainless steel ring seam automatic welding machine;
Carbon steel/stainless steel/copper/aluminum and other MIG TIG SAW welding machines;
Welding Chuck/Gun Holder/Pneumatic Tailstock/Support Rack.
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
800kg Tilt Welding Turning Table for Flange Welding
