Advanced Great Quality High Speed Accurate Carbon Steel Copper Plate 8-Cylinder Welding Machine

Get the latest advanced 8-cylinder welding machine with high speed and accuracy. Our factory's carbon steel copper plate welding machine ensures great quality. Shop now!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Parameters
  • Representative products
  • Company Profile
  • Certifications
  • Exhibition
  • Pay for logistics
  • FAQ
Overview

Basic Info.

Model NO.
XSZN-Gantry welding machine
Conductive Way
Both-Sided
Welding Spot Number
Single
Type
Universal
Video Outgoing-Inspection
Provided
Machinery Test Report
Provided
Core Components
PLC, Engine, Bearing, Gearbox, Motor, Pressure Ves
Warranty
1 Year
Key Selling Points
Automatic
Applicable Industries-1
Building Material Shops, Machinery Repair Shops
Applicable Industries-2
Manufacturing Plant, Construction Works
Applicable Industries-3
Energy & Mining
Product Name
Stainless Steel Spot Welder Machine
Machine Type
Welding Rotator
Max Wire Speed
16.8m/S(2.0mm, 1500kg/H)
Transport Package
Wooden Box
Specification
2160mm*720mm*1900mm
Trademark
Xin Sheng
Origin
Ningbo
HS Code
85152100
Production Capacity
10000

Product Description

8-22cylinder gantry wire mesh welding machine
Product Parameters
Standard gantry
specifications
Number of cylinders Controller Transformer power Effective welding stroke
(mm)
Rated primary voltage (V) Rated power
(HZ)
Maximum current
(A)
Load endurance rate 100% Cooling water (L/min) Adjustable electrode stroke (mm) Weight (KG)
1.2M 8
cylinder
2 100KVA2 920 380 50/60 30000 50 10 95 1500
1.4M 10
cylinder
2 150KVA2 1200 380 50/60 36000 50 12 95 1700
1.6M 12
cylinder
2 150KVA2 1400 380 50/60 36000 50 12 95 2100
1.8M 16
cylinder
2 150KVA2 1600 380 50/60 36000 50 12 95 2300
2.5M 22
cylinder
2 200KVA2 2000 380 50/60 42000 50 14 95 3000
Advanced Great Quality High Speed Accurate Carbon Steel Copper Plate 8-Cylinder Welding Machine
Product advantages:
The capacitor energy storage machine uses capacitors to store energy and instantly release current. At the same time, a large current is concentrated to pass through the contacts of the welded parts to generate resistance heat and achieve fusion effect. The standard power of the capacitor energy storage machine produced by our company is 300-50000J, and its advantages are as follows:
Widely applicable: Able to weld up to 5MM stainless steel and non-ferrous metals such as copper, aluminum, aluminum, and silver, overcoming the difficulty of welding dissimilar metals such as copper and aluminum.

Firm and beautiful: The welding is firm, with no blackening at the welding points, eliminating the polishing process, making it particularly suitable for processing export-oriented products.

Energy saving and energy-saving: This type of machine has low instantaneous power and high power factor from the power grid. Compared with power frequency machines with the same welding force, it only uses 1/7-1/10 of electricity and has low operating costs. It uses the world's excellent Japanese "HEM1CON" emergency charging and discharging capacitor, and its extremely high service life (3.5 times that of other capacitors) ensures the quality of the equipment to be the most effective.

Related technology and parts description:
A. Adopting a double-layer manual feeding, automatic feeding, automatic welding, and automatic unloading device, utilizing advanced PLC control system and flexible human-machine interface control, as well as precise servo motor drive system, a continuous automatic feeding and welding mechanism is formed. The welding machine has two sets of workpiece molds, front and back. When welding in one mold, other molds place the workpiece. After welding, the two molds exchange workstations to continue welding and placing the workpiece. And through the human-machine interface and PLC controller, it is convenient to weld different specifications of mesh, while storing and memorizing more than 100 mesh sequences.

B. This machine has stable welding and simple operation. Reduce physical exertion of personnel, reduce labor intensity, and have low technical requirements for operators. Generally, personnel can start working after about 2 days of training. Simultaneously, more effectively improving production efficiency and product quality.

C. The gantry welding machine adopts a ¥ 80mm three-stage pressurized cylinder manufactured with original Japanese structural drawings, which is lightweight and flexible, with buffering function. The cylinder stroke can be adjusted according to needs, with the maximum stroke reaching 80mm, effectively ensuring and balancing the pressure during welding, and achieving the best welding effect. The cylinder placement adopts a dovetail groove hanging fixing method, and the lower copper electrode is combined with a T-shaped groove and trapezoidal copper, which can be flexibly adjusted according to the welding changes of the workpiece. At the same time, the lower copper electrode is equipped with a double lower cylinder with a stroke of 20mm and a stroke of 50mm, and the double lower cylinder also has a 35mm stroke adjustment function to facilitate the adjustment of different molds and injection stroke. The double lower cylinder is equipped with a balance uranium to ensure that both ends are balanced and rise in place simultaneously.

D. This machine adopts dual transformers at both ends to provide welding current, which effectively ensures the stability and balance of the current in each cylinder. It also uses a dual control box combined with a PLC control system for functional operation control. The cylinder can be stopped or operated at any time. Simultaneously equipped with dual current function.

E. The servo motor relies on imports and self-developed servo wiring.

F. Imported global brand reducers.

G. Import global brand PLC control systems and related electronic components.

H. Imported original guide rails.

I. Heavy duty aluminum profile skeleton.

J. Imported solenoid valves and thyristors.

K. Transformers, cylinders, and other products are self-made, originating from the appearance design of Japan and Taiwan, with stable quality.

L. The control box is self-made using Taiwan's original circuit board. The casing is made of high-strength steel plate, and the structural design originated from Japan. The control box design adopts the principle of Japanese original control box design and the assembly of original Taiwan circuit board, with constant current and constant pressure functions available for selection. The control box has a grid voltage compensation function, with three current segments to choose from, and can store 15 welding specifications, including slow current rise and fall.

M. The foot switch has excellent quality, imported with care, beautiful appearance, and long service life.
