Automatic Cylinder Pipe Welding Station Manipulator Column and Boom

Find the best Automatic Cylinder Pipe Welding Station Manipulator Column and Boom at our factory. High-quality and precise welding solutions for your industrial needs." This SEO description is 156 characters long.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Product Features
  • Packaging & Shipping
Overview

Basic Info.

Model NO.
HJ
Welding Tilter Type
Flexible Combination
Condition
New
Name
Column Boom Welding Manipulator
Working for
Pipe Tank Vessel Automatic Arc Welding
Optional
Welding Positioner and Welding Rotator
Column Stroke
1m-10m
Boom Stroke
1m-10m
Input Voltage
380-480V
Exported to
Finland, Greece, Canada, South Africa, USA, Poland
Warranty
1 Year
After Sales
Online Engineer
OEM
Yes
Lead Time
25 Days
Column Rotation
180 Degree
Moving Type
Electric or Manual
Speed Regulation
VFD
Lifting Speed
450-1000mm/Min
Transport Package
Standard Package
Trademark
Lemar
Origin
Wuxi, China
HS Code
8515319900
Production Capacity
1000 PCS/Year

Packaging & Delivery

Package Size
600.00cm * 530.00cm * 820.00cm
Package Gross Weight
5500.000kg

Product Description

Product Description

Automatic cylinder pipe welding station manipulator Column and boom
For the fabrication of pipes and tanks, Wuxi Lemar Company offers high-quality automated welding machine systems.
Automatic pipe welding systems are only one example of the many applications that can benefit from welding automation positioning systems.
Tank building applications, such as welding vessels and storage tanks' girth seams, require automated tank welding fabrication equipment. arc column booms for submerged arc welding, manipulators, turning rolls, turntables, and linear side beams.

Automatic Cylinder Pipe Welding Station Manipulator Column and Boom
Automatic Cylinder Pipe Welding Station Manipulator Column and Boom
Automatic Cylinder Pipe Welding Station Manipulator Column and Boom
Product Parameters
Technical parameters/model HJ1010-3030 HJ4040 HJ5050 HJ6060 HJ7070-8080 HJ9090-120120
Structure type Optional:Fixed type,Manual rotation,Electric rotation,Moving and rotation
Lifting stroke (mm) 1500-3000 4000 5000 6000 7000-8000 9000-12000
Telescopic stroke (mm) 1500-3000 4000 5000 6000 7000-8000 9000-12000
Speed regulation mode of wishbone Frequency
Lifting speed 450mm/min 1000mm/min
Telescopic speed (mm/min) 100-1000mm/min
Small distance between the lower edge of the cross arm and the track surface (mm)   1100 (mobile rotary)
950 (fixed rotary)
1118 (mobile rotary)
1170 (fixed rotary)
Allowable large load in front of cross arm (kg) 100 200 300

Column rotation
±180°
0.36rpm or manually
  2000
Trolley walking 1200 2000 2200 2500
Inner gauge of trolley (mm) Manual and pneumatic 2 options
locking mechanism Wired Hand Control Box
Remote control box cable power supply 220V/380V/400V/415V/440V/460V-3P-50HZ/60HZ
power supply Gas shielded welding, mig welding, tig welding
  Gas shielded welding is suitable for plate thickness ≥ 3mm.
The main applicable materials are: carbon steel stainless steel aluminum plate
  Submerged arc welding is mainly used for ≥6mm plates, mainly carbon steel, but also stainless steel. It is recommended to choose a water-cooled welding torch and a water-cooler to prevent the welding temperature from being too high.
Product Features

1. The column of Welding manipulators is a rectangular beam, and the rectangular double guide rail structure is made of high-quality steel, which is reprocessed after welding;
2. The guide seat is well stressed, the contact surface of the guide wheel is wide, and the transmission is relatively stable and reliable;
3.Welding manipulators cooperate with welding rotators, welding positionsers do not need manpower to flip, easy to operate
4. Constant torque frequency conversion control motor drive, strong load capacity, good stability at low speed
5. High-precision gears with sufficient rigidity to ensure the high precision of column and boom welding manipulators
