Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding

Premium quality Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, and Cladding Welding equipment at competitive prices. Factory direct. Shop now!" For SEO purposes, use relevant keywords like "welding machine", "chemical machinery", "pressure vessels", "welding manipulator", and "cladding welding" to improve search engine rankings.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
PR5
Welding Turning Rolls Type
Self-Adjusting
Welding Tilter Type
Flexible Combination
Condition
New
Size
Wm3030
Head
Cross Slide
Annex
Laser Tractor ,Weld Camera
Transport Package
Nude
Trademark
DESAN
Origin
China
HS Code
84688000
Production Capacity
1000

Product Description

Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding      pipe prefabrication automatic welding machine

pipe prefabrication automatic welding machine is specially designed and manufactured for the purpose of meeting the requirements of enhancing productivity, increasing the extent of automatic, reducing welder's working intensity and adapting to piping workshop prefabrication. The welding head will be relatively fixed, while the piping spool piece revolving at a specific rate, and the high efficient and low cost shielded welding or SAW process is adopted, so it has the features of easy-operation, reliable-performance and wide-application field.


pipe diameter applicable         φ50~φ426mm
welding speed                   70~1700mm/min
welding process                 MIG,MAG,SAW
      seams                          pipe+pipe,pipe+piece,piece+piece


Automatic girth seam machine TIG,MIG/MAG,PLASMA,,,,,,,,.
Applicable for the welding of various cylinder workpiece by TIG, MIG, MAG and PLASMA,its structure including horizontal, stand and adjustable principal axis, and assembling with headstock, lathe bed, bracket ,control system etc.

Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding

     For all arc welding processes, it is important that the welding head be rigidly mounted over the part to be welded to obtain the highest quality weld results. Any vibration or instability of the weld head mounting will have an effect upon the arc length and produce inferior results. Welding manipulator is used when the weld head has to be moved to a position relative to the work piece. Welding manipulator provide the perfect solution as the boom can be lifted and lowered on the column and can be extended or retracted as required, The ends of  boom are machined to carry a welding head.
This machine and welder composed of auto welding mechanical equipment. It can use with welding rotator, widely applied to industries such as boiler, pressure vessel, petroleum, chemical industry and mechanism.
+ Structure : stationary, stationary and revolve , moving and revolve type.
+ Cross section of boom and column are rectangular-section beams, with double-rail, welded into shape,stress-relieved and mechanical machined finely, ensuring higher precision;
+ Drooping of boom along horizontal travel is 2mm/m.
+ Boom lifting device including ratchet-type anti-dripping unit on the column, safe and reliable to prevent chains from incidental broken.
+ Guide roller is eccentric structure, decrease clearance between roller and rail surface, ensuring smooth and no shivering boom travel.
+ Column revolve unit has motor -driven and manual drive type.
+ Control box includes control box and pendant , interface with positioner and rotator also prepared

Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding


Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding


Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding



Elbow Pipe Welding Machine Chemical Machinery, Pressure Vessels, Use Welding Manipulator, Boom and Column of Cladding Welding




Notes:
a) Column motorized rotation: included only WM 3030 and above
b) Trolley motorized with constant speed: included
c) Remote control box with 6-12 m span: included
d) Manual welding head cross slide: included
e) Boom cable organizer: export product included
f) Boom anti-fall safety device on WM 3030 and above: included
g) Trolley anti-fall safety device: included
h) Power source platform on trolley: included
i) Shot blasted frame at SA 2 ½: included
j) Custom built welding manipulators available
k) CE mark only under customer request
l) Manual revolve then locked by screw
m) The information contained in this brochure is intended to be
accurate. However the manufacturer retain the rights to make
changes in design which may not be include
Standard package includes
  Welding Manipulator and traveling cart
  Remote control box adjust: i) Vertical and horizontal boom
movement; ii) Trolley motion
  Operation manual
  One year warranty
Optional
• Flux recovery unit
• Electric welding head cross slide
• Trolley cable organizer
• Rail track for trolley
• Variable speed on traveling cart from 0.12 up to 1.20 m/minute
• Work platform and operator's seat only in WM 5050 and larger
• Seam tracker
• Seam monitor system
• Welding oscillator
• Arc length control
• drive by linear ball bearing guide rail











Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
