Single Axis Welding Positioner Tube Welding Turntable

Get precise and efficient tube welding with our Single Axis Welding Positioner Tube Welding Turntable. As a factory, we offer top-quality equipment for your welding needs.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
Overview

Basic Info.

Model NO.
BWJ
Condition
New
Model
Bwj-6
Positioner Function
Robotic Welding Platform Rotary Positioner
Loading Weight
600kg
Rotary Table Size
350mm
Rotating Speed of Table
60 Degree/Min
Tilt Angle
0-90 Degree
Servo Motor
0.37kw
Lead Time
5 Days
Height Adjustment
Customized
Length Adjustment
Customized
Exported to
Europe,USA,UK,Russia etc
Warranty
1 Year
Positioner Height
760mm
Brand
Lemar
Control Method
Foot Switch
Transport Package
Wooden
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Production Capacity
3000PCS/Year

Packaging & Delivery

Package Size
120.00cm * 75.00cm * 60.00cm
Package Gross Weight
600.000kg

Product Description

Product Description

Single Axis Welding Positioner Tube welding turntable

The 600kg welding positioner is an invaluable tool for any welding operation. It is designed to allow welders to easily rotate and position workpieces, making welding easier and more efficient.
1. The automatic rotary positioner has a load capacity of 600 kg, making it easy to handle even the heaviest workpieces. This means it works on a variety of materials, including steel, aluminum and other metals.
2. Achieve smooth and accurate rotation of the workpiece by using high-quality motors and gearboxes to ensure that the workpiece rotates at a constant speed with minimal vibration. This not only improves welding quality but also reduces the risk of workpiece damage.
3.600 kg Welding Positioner It can be used in various welding applications including MIG welding, TIG welding and rod welding. This makes it a valuable asset to any welding operation, regardless of the type of welding performed.

Overall, the 600kg welding positioner is a must-have for any welding operation looking to improve efficiency, productivity and quality.
Its strong load-bearing capacity, smooth rotation, and versatility make it an excellent investment for any welder or welding business.
Product Parameters
No. Item Model:BWJ-6
1 Loading weight(kg): 600
2 Rated eccentricity (mm): 100
3 Maximum center of gravity distance (mm): 100
4 Flip mode: Electric flip
5 Table height(mm): 760
6 Flip angle: 0-900
7 Speed mode: Rotary frequency stepless speed regulation
8 control method: Foot switch
9 Voltage: 380V-3PH-50HZ
10 Rotate speed 0.12~1.8rpm(customized)
11 Flip speed 0.8rpm
12 Tilt Motor 0.75KW
13 Rotate Motor 0.37KW
14 Tilt angle 0-90°

Specification of Dual axis automatic turning table Robot  welding positioner:

Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Except the normal benchtop welding positioner,we Wuxi Lemar also have the robotic welding positioner,such as head tail stock welding positioner,L type welding positioner,and other welding turntables.
By automatically adjusting the position of the workpiece, head and tail robotic welding positioners can also help reduce operator fatigue and improve welding process safety.
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
How to choose a good rotary welding positioner turntables supplier?
1. Professional knowledge and experience: It is very important to choose a supplier with rich experience, profound knowledge and professional knowledge in the field of automatic welding and cutting beveling such as pipe flanges and cylinders, and a supplier with a good reputation is required.
2. Product Quality: When selecting a supplier, it is important to ensure that they provide high-quality products. Examine the materials used, construction techniques and the overall durability of the product.
Wuxi Lemar is mainly engaged in research and development, manufacture and sale, CNC Plasma cutting machine and Automatic welding equipment such as H-beam welding production line (light type, heavy type), box beam welding production line, horizontal assembly&welding production line, adjustable welding rotator, self-aligning welding turning rolls,seat type welding positioner,robotic welding turning assembly positioner,Customized positioners,3 jaw 4 jaw welding chuck,Straight seam welding machines,Circular seam welding machines,Column and boom TIG MIG SAW Tank and vessel welding manipulators, etc.,
3. Customer Service: A good supplier should provide excellent customer service. They provide technical assistance and assist with any issues that may arise.
4. Customization: It is important to choose a supplier who can provide a customized solution to meet your specific needs. Find a supplier who can work with you to understand your requirements and provide a custom solution. Wuxi Lemar can produce welding positioner, welding rotator and welding manipulators customized.
5. Pricing: Pricing is an important factor when selecting a supplier. Look for suppliers who offer competitive prices without compromising quality.
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
Single Axis Welding Positioner Tube Welding Turntable
