Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

Looking for top-quality welding rotators? Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator - all manufactured in our factory.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Customers of Zhou Xiang
  • Main Products
  • Company Profile
Overview

Basic Info.

Model NO.
GLHZ
Condition
New
Name
Welding Rotator
Roller Material
Rubber or PU or Metal
Certificates
CE ISO
Max Load Weight
250000kg or as Your Request
Range of Suitable Workpiece
1200-7000mm or as Your Request
Transport Package
Steel Frame
Trademark
Zhouxiang
Origin
China
HS Code
8468800000
Production Capacity
50sets/Month

Product Description

Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator
Type

Max load weight(kg)

Suitable diameter of vessel(mm)

Diameter and width of the wheel

Roller linear speed(m/h)

Power of motor(kw)







Rubber

rollers(mm)

Metal

rollers (mm)





GLHZ-5

5000

φ250-φ2300

φ250*100

2*φ240*20

6-60

0.75

GLHZ-10

10000

φ320-φ2800

φ300*120

2*φ290*25

6-60

1.1

GLHZ-20

20000

φ500-φ3500

φ350*120

2*φ340*30

6-60

1.5

GLHZ-40

40000

φ600-φ4200

φ400*120

2*φ390*40

6-60

3

GLHZ-60

60000

φ750-φ4800

φ450*120

2*φ440*50

6-60

4

GLHZ-80

80000

φ850-φ5000

φ500*120

2*φ490*60

6-60

4

GLHZ-100

100000

φ1000-φ5500

φ500*120

2*φ490*70

6-60

5.5

GLHZ-150

150000

φ1100-φ6000



φ600*280

6-60

7.5

GLHZ-250

250000

φ1200-φ7000



φ700*300

6-60

2*5.5

GLHZ-500

500000

φ1800-φ8000



φ850*350

6-60

2*7.5


Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator
Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

1.Welding rotator each structural member after welding to be annealed, and then processed to ensure the long-term performance and service life. It has reasonable structure and steel is good, all mechanical transmission wear resistance and with the corresponding dust means.

2.Four wheel roller frame are active wheel, dual-drive system, drive motor with AC motor drive system has over-current protection, overload protection and other functions.

3.Transmission mechanism are: motor - a multi-stage speed control the scroll wheel , speed Adjustable Frequency.

4.Wheel frame base having sufficient strength rigidity. At the rated load, lower roller airplane flexible deformation does not affect the normal use of the equipment, while the roller frame with a certain overload.
Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

Customers of Zhou Xiang

Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

Main Products

Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator

Company Profile

Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorWuxi Zhouxiang Complete Set of Welding Equipment Co.,Ltd,founded in 1991,located in Wuxi city, about 100km from Shanghai.We have fixed assets of 150 million yuan,cover an area of 160,000 m2, staff 500 people,including more than 100 engineering and technical personnel.Our company was certified to ISO9001 Quality System Certification firstly in the industry and many products were certified to China Compulsory Certification(CCC).Our products sell well at home and abroad,including Europe,America,Southeast Asia,Middle East and other countries.
Zhouxiang products mainly include CNC flame/plasma cutting machine,H beam light duty production line,H beam heavy duty production line,Horizontal H beam production line,H beam assembly welding straightening integral machine,Corrugated web H beam production line,Box beam production line, Welding manipulator, Rotator, Positioner,Edge milling machine,End face milling machine,Shot blasting machine series,kinds of plate rolling machine,Profile bending machine and welders,fiber laser cutting machine,CO2 laser cutting machine,laser tube cutting machine,Fiber laser cutting robot and Fiber laser welding robot etc.

We have high sincerity to do business with customers all over the world and establish good friendships.
Zhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding RotatorZhouxiang Vessel Automatic Turning Rolls Tank Rollers Weld Rotary Wuxi Welding Rotator
