Zhr-60 Headstock and Tailstock Welding Positioners

Zhr-60 Headstock and Tailstock Welding Positioners for precision welding. Shop now at our factory for high-quality, reliable welding equipment.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
ZHR-60
Condition
New
Lead Time
10 Days
After-Sales Service
Video Technical Support, Online Support
Warranty
13 Months
Transport Package
Export Standards
Trademark
Fengwei
Origin
China
HS Code
8428909090
Production Capacity
320 Sets/Month

Product Description

 Product Description



Headstock and tailstock positioner is typically used for long and large rectangular work pieces in different applications and being supported by both ends. The machine consists of elevation and rotation function for ergonomic placement of the weldment. They are available fro manual (light capacity) to robotic interfacing (heavy-duty). With customized variable speed setting, all welding processes can be accommodated, such as MIG, TIG, SAW and robotic welding.

Head and tailstock positioner provides higher efficiency to eliminate overhead and manual positioning and optimize the fabrication process. Therefore, such assistant machine improves work efficiency and reduce work downtime.

This type of machine is widely used in Kazakhstan, Finland etc.

Technical Parametre

Model ZHR-20 ZHR-40 ZHR-60 ZHR-100 ZHR-120 ZHR-150 ZHR-200 ZHR-250 ZHR-300
Capacity (ton) 2 4 6 10 12 15 20 25 30
Min height (mm) 350 350 500 500 550 550 550 700 750
Max height (mm) 1900 1900 1950 1950 2000 2000 1850 1850 2000
Lifting stroke (mm) 1550 1550 1450 1450 1450 1450 1300 1150 1250
Lifting speed (mm/min) 560 560 560 650 650 650 560 470 290
Table tilting torque moment (Nm) 3000 3500 5500 7500 15000 15000 22000 25000 35000
Max table rotation speed (rpm) 1 1 0.75 1.1 1.1 1.1 0.9 0.9 0.75
Table diameter (mm) 600 600 800 900 1000 1000 1000 1300 1450
Electric motor power 1.85 1.85 1.85 2.2 3 3 3.7 4 4
Electric motor power 9.75 0.55 0.55 1.1 1.5 2.2 3 3 3





Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners
Zhr-60 Headstock and Tailstock Welding Positioners


Capacity (ton)
